3. LUBRICATION SYSTEM
3-6
Install the oil pump cover and fixing pin properly
Tighten screw
Make sure that oil pump shaft can be rotated
freely.
Oil Pump Installation
Install the oil pump, and then tighten bolts.
Torque value: 0.8~1.2 Kg-m
Make sure that oil pump shaft can be rotated
freely.
Install oil pump driving chain and sprocket, and
then install snap ring onto oil pump shaft.
Install starting gear and generator.
SCREW×1
