2. Maintenance Information
2-10
Remove brake lining bolt.
Take out the lining.
Caution
In order to maintain brake power balance,
the brake lining must be replaced with one
set.
Brake Light Switch
The brake lamp switch is to light up brake lamp
as brake applied.
Make sure that electrical starter can be operated
only under brake applying.
Headlight Beam Distance
Turn on main switch
Turn the headlight adjust screw with driver to
adjust headlight beam high.
Caution
To adjust the headlight beam follows related
regulations.
Warning
Improper headlight beam adjustment will
make in coming driver dazzled or insufficient
lighting.
Clutch Weight
Run the motorcycle and increase throttle valve
opening gradually to check clutch operation.
If the motorcycle is in forward moving and
shaking, check clutch disc condition. Replace it
if necessary.
Lining bolt
Lining
Master
c
linder
Brake switch
d
ust screw
