Sym X'PRO RV125 User Manual

3. LUBRICATION SYSTEM
3-1
Precautions in Operation..................3-2
Troubleshooting................................3-2
Engine Oil ..........................................3-3
Engine Oil Strainer Clean .................3-3
Oil Pump Removal.............................3-4
Oil Pump Disassembly ..................... 3-4
Oil Pump Inspection ......................... 3-5
Oil Pump Reassembly ...................... 3-5
Oil Pump Installation ........................ 3-6
Gear Oil.............................................. 3-7
VALVE ROCKER ARM
CAM SHAFT
Press-In Lubrication
CON-ROD
OIL PUMP
OIL STRAINER
Press-In Lubrication
Spray Lubrication
Spray Lubrication
Oil Route
Oil Route
Rotate Direction
