14. Body Cover
14-8
Center Cover
Removal
Remove the center cover screws.
Remove the center cover.
Installation
Install in the reverse order of removal.
Body Covers / Rear Fender
Removal
Remove the body cover screws on the front
side.
Remove the body cover bolts on the rear side.
Disconnect the taillight / rear winker coupler.
Remove the body cover / rear fender
assembly.
Installation
Install in the reverse order of removal.
4 screws
2 screws
3 bolts
To this chapter contents
Taillight / rear winker coupler
