Mechanism Illustration
Front winker
Fuel tank
cap
Luggage box
Light switch / start switch /
engine stop (hazard) switch
Dimmer switch / winker switch /
horn switch / seat open (passing)
switch
Muffler
Reserved tank
cap
Coolant filler
cap
Ignition / Seat open
switch
Fuse
Main switch
Fuel tank /
fuel pump
Side stand
ECU /
throttle body
B
ack mirror
Battery
Front brake
lever
Rear brake
lever
Home page
Contents
Main stand
Air cleaner
Taillight /
rear winker
