Tenda O3 User Manual

109
7.3 Access Control
7.3.1 Overview
It specifies, based on MAC address filter rules, the wireless devices that can or cannot access the wireless
networks of the CPE. The CPE supports the following MAC address filter rules:
− Disallow: It indicates that only the wireless devices with the specified MAC addresses cannot access
the wireless networks of the CPE.
− Allow: It indicates that only the wireless devices with the specified MAC addresses can access the
wireless networks of the CPE.
7.3.2 Configuring Access Control
Configuration Procedure
Step 1 Choose Wireless > Access Control.
Step 2 Enable the Access Control function.
Step 3 Select a MAC address filter mode, Disallow or Allow.
Step 4 Enter the MAC addresses to control in the access control list and click Add.
If the wireless devices to be controlled are connected to the CPE, directly click Add online devices to
add them to the access control list quickly.
Step 5 Click Save.
----End
Access Control List

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
