Tenda O3 User Manual

157
9.4 System Log
To access the page, choose Tools > System Log.
The logs of the CPE record various events that occur and the operations that users perform after the CPE starts.
In case of a system fault, you can refer to the logs during troubleshooting.
To ensure that the logs are recorded correctly, verify the system time of the CPE. You can correct the system time
of the CPE by choosing Tools > Date & Time.
To view the latest logs of the CPE, click Refresh. To clear the existing logs of the CPE, click Clear.

When the CPE reboots, the previous logs are lost.

The CPE reboots when the CPE is powered on after a power failure, the VLAN function is configured, the firmware is
upgraded, a CPE configuration is backed up or restored or the factory settings are restored.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
