Tenda O3 User Manual

1
1 Introduction
1.1 Overview
The Tenda outdoor point to point CPE is dedicated for WISP solutions and video surveillance in elevators, tower
cranes, apartments, factories, orchards, and scenic areas. Featured the built-in high-gain antennas, and the
refined exterior design, the device can be installed onto walls or poles, and offers strong and stable WiFi signals.
The industry grade waterproof and dustproof housing allows it to work properly even in harsh environments.
With auto-bridging technology, two CPEs can connect to each other automatically to make setup a breeze.
1.2 Getting to Know Your Device
1.2.1 Appearance of O1
LED Indicators
O1
LED Indicator
Status
Description
PoE/LAN
Solid on
The device is being powered properly, and no data is being transmitted.
Blinking
Data is being transmitted over the port.
Off
The device is not powered on.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
