Tenda O3 User Manual

133
----End
Parameters Description
Name
Description
DDNS
It Specifies whether to enable the DDNS function.
Service Provider
It specifies Dynamic Domain Name Service provider. The CPE supports Dyndns, No-ip.com, and
3322.org.
User Name
It specifies the user name used to log in to the dynamic DNS service, as well as the Login user name
you registered on the website of the service provider.
Password
It specifies the password used to log in to the dynamic DNS service, as well as the Login password
you registered on the website of the service provider.
Domain Name
It specifies the domain name information obtained from the dynamic DNS server. You need to
enter the domain name which you registered on the website manually.
Examples of Configuring DDNS
Networking Requirement
The CPE is used in a company to deploy its network, and it is set to Router mode. The WAN IP address of the CPE
is dynamic.
Requirement: The administrator on business can visit the resources on web server in LAN.
You are recommended to use the DDNS and port forwarding functions to solve the problem.
Assumption:
The information of the web server in LAN is shown as follows:
IP Address: 192.168.2.100
Service Port of the Web Server: 80
The registered domain name information is shown as follows:
Service Provider: Dyndns

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
