Tenda O3 User Manual

147
8.6.9 UPnP
Universal Plug and Play (UPnP) is a set of networking protocols that makes automatic port forwarding possible. It
can identify devices and enable ports for certain applications, such as Thunder. To use this function, it requires
that the operating system support UPnP, or application software supporting UPnP is installed.
Choose Advanced > Network Service to enter this page. By default, the function is enabled.
8.6.10 Hardware Watch Dog (Only for O3)
This function uses an embedded watchdog timer to detect the operation condition of the device’s main program
at scheduled time. During normal operation, the device regularly resets the watchdog timer to prevent it from
elapsing, or "timing out". If, due to a hardware fault or program error, the device fails to reset the watchdog
timer, the timer will elapse and generate a timeout signal. The timeout signal is used to reboot the device to
make it recover from malfunctions.
Choose Advanced > Network Service to enter the page. By default, the function is enabled.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
