Tenda O3 User Manual

58
5 Status
This module allows you to view the information of system and wireless network.
5.1 System Status
Log in to the web UI of the CPE, and choose Status. You can view the system status here.
If the CPE is set to AP mode, Client mode, Universal Repeater mode, Repeater mode or P2MP mode, the
system status is shown as follows:
Parameters Description
Name
Description
Device Name
It specifies the name of this device. If this device is not the only one of its kind in the network,
this name helps you identify the device. You can change the name of this device on the
Network > LAN Setup page.
Uptime
It specifies time during which this device is operating.
System Time
It specifies the current system time of this device.
Firmware Version
It specifies the system software version number of this device.
Hardware Version
It specifies the hardware version of this device.
LAN MAC Address
It specifies the MAC address of LAN port of this device. When connecting to another device
using an Ethernet cable, the CPE uses this MAC address to communicate with the device.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
