Tenda O3 User Manual

141
----End
Parameters Description
Name
Description
SNMP Agent
It specifies whether to enable the SNMP agent function of the AP. By default, it is disabled.
An SNMP manager and the SNMP agent can communicate with each other only if their SNMP
versions are the same. Currently, the SNMP agent function of the CPE supports SNMP V1 and
SNMP V2C.
Device Name
It specifies the device name of the CPE. The default device name is the model and version
number of the CPE. For example, the default name of this device is O3V2.0
It is recommended that you change the CPE name so that you can easily identify the CPE
when managing the CPE using SNMP.
Read Community
It specifies the read password shared between SNMP managers and this SNMP agent. The
default password is public.
The SNMP agent function of the CPE allows an SNMP manager to use the password to read
variables in the MIB of the CPE.
Read/Write Community
It specifies the read/write password shared between SNMP managers and this SNMP agent.
The default password is private.
The SNMP agent function of the CPE allows an SNMP manager to use the password to
read/write variables in the MIB of the CPE.
Location
It specifies the location where the AP is used. You can change the location as required.
Example of Configuring the SNMP Function
Networking Requirement
− The CPE connects to an NMS over an LAN. This IP address of the CPE is 192.168.2.1/24 and the IP
address of the NMS is 192.168.2.212/24.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
