Tenda O3 User Manual

67
6 Network
6.1 LAN Setup
6.1.1 Overview
Log in to the web UI of the CPE, and choose Network > LAN Setup to enter the page.
This page enables you to view the MAC address of the LAN port, and set up the device name, and type of
obtaining an IP address and related parameters.
Parameters Description
Name
Description
MAC Address
It specifies the MAC address of LAN port.
The default SSID of the CPE is Tenda_XXXXXX, and XXXXXX is the last six characters of this MAC
address.
IP Address Type
It specifies the type of obtaining an IP address. The default is Static IP Address.
Static IP Address: Specify the IP address, subnet mask, default gateway, and DNS server IP
addresses manually.

Tenda O3 Specifications

General

5 GHz	No
2.4 GHz	Yes
Number of users	15 user(s)
Transmitting power	29 dBmW
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	MCS0: -88dBm MCS7: -72dBm
Maximum outdoor range	5000 m
Maximum data transfer rate	150 Mbit/s
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Placement	Wall
Certification	FCC / CE / RoHS
Product color	White
LED indicators	LAN, Power, WAN
International Protection (IP) code	IP64
Antenna features	Integrated antenna
Antenna gain level (max)	12 dBi
Output current	1 A
Output voltage	12 V
Power consumption (max)	6 W
Security algorithms	WPA, WPA2, WPA2-PSK
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	94.86 mm
Width	270 mm
Height	67.5 mm
