FUEL SYSTEM - Injection Nozzles (1 PZ and 1 HZ) FU-15
3. INSTALL INJECTION PIPES
(a) Place the two clamps on the intake manifold.
(b) Connect the injection pipes to injection nozzle.
Torque: 150 kg-cm (11 ft-lb, 15 Nm)
(c) Connect the injection pipes to injection pump.
Torque: 150 kg-cm (11 ft-lb, 15 Nm)
(d) Secure the injection pipes with clamps and bolts.
4. INSTALL INTAKE PIPE
(See step 3 on page EM-38)
5. START ENGINE AND CHECK FOR FUEL LEAKS
