FUEL SYSTEM Injection Pump FU-45
28. REMOVE FUEL FEED PUMP
(a) Remove the two screws.
(b) Using a piece of wire, remove the feed pump cover.
(c) Remove the feed pump rotor, four blades and liner.
NOTICE:
• Be careful not to interchange the blade positions.
• Be careful not to damage the pump body.
29. REMOVE REGULATOR VALVE
Using SST, remove the regulator valve and two O-rings.
SST 09260-54012 (09262-54020)
30. REMOVE FUEL INLET HOLLOW SCREW
Remove the hollow screw and gasket.
To Next Page
