FUEL SYSTEM - Injection Pump FU-39
(b) Using a small screwdriver, push out the support pin
and remove the control lever.
(c) Using needle nose pliers, remove the connecting pin.
NOTICE: Be careful not to damage the connecting
pin. Tape the tip of the pliers.
E. Remove ISIo.2 PCS lever
Remove the following pars from the the governor cover.
(1) No.2 lever, O-ring and washer assembly
(2) O-ring
(3) Washer
F. Remove No.2 overflow screw
Remove the cover and No.2 overflow screw.
17. CHECK FLYWEIGHT HOLDER THRUST CLEARANCE
(See step 20 on page FU-58)
Thrust clearance: 0.15 - 0.35 mm
(0.0059-0.0138 in.)
