CH-11
CHARGING SYSTEM - Alternator
(c) Using SST, remove the rectifier end frame.
SST 09286-46011
(d) (Type A)
Remove the alternator washer.
6. REMOVE ROTOR FROM DRIVE END FRAME
SST
Type A
CH0870
CH0879
CH0851
