Whirlpool Cabrio WTW8500DC User Manual

COMPONENT ACCESS
Whirlpool 2014 CABRIO
®
Direct Drive Washer
n
4-1
Section 4:
Component Access
This secon provides service parts access, removal, and
installaon instrucons for the “Whirlpool 2014 CABRIO® Top
Load Direct Drive Washer.”
n Component Locaons
n Removing the Console-Method A
n Removing the Console-Method B
n Removing the User Interface (UI)
n Removing the Water Inlet Valve
n Removing the Main Control
n Removing the Tub Ring, Impeller, and Basket
n Removing the Motor and Drive Assembly
n Removing the Pumps
n Removing the Heater
n Removing the Lid Lock
n Removing the Lid and a Hinge

Whirlpool Cabrio WTW8500DC Specifications

General

Style	Top-Loading
Color	Chrome Shadow
Washer Capacity	5.3 cu ft
Dryer Capactity	-
Max Spin Speed	850 RPM
Spin Speeds	2
Spin Class	D
Number of Cycles	26
Cycle Selections	Drain & Spin
Wash	Towels
Options	Clean Water
No spin and No heat	Extra Rinse
Hours	Delay Wash
Noise level	-
Temperature Selections	-
Cold)	Eco Warm
Internal Heater	yes
Delay Start / End	yes
Cycle Signal	yes
Steam	yes
Dispenser	single load
Energy Class	-
Annual Energy Consumption	196 kWh
Annual Water Consumption	-
Water Consumption Per Cycle	-
Voltage	120 V
Frequency	-
Current	15 A
Temperature Settings	5
Soil Levels	light, medium, normal, heavy
Smart Home	no

Weight and Dimensions

Depth	27-7/8 in
Height	42-1/8 in
Width	27-5/8 in
Net Weight	160 lb
