Whirlpool Cabrio WTW8500DC User Manual

5-8
n
Whirlpool 2014 CABRIO
®
Direct Drive Washer
DIAGNOSTICS & TROUBLESHOOTING
For Service Technician Use Only
Soware Version Display
NOTE: The Soware Version Display mode will me out aer
5–10 minutes of user inacvity and return to standby mode.
Entry Procedure
To enter Soware Version Display, press and hold the 2nd
buon used to acvate the Service Diagnosc mode for 5
seconds. Upon entry, all LEDs on the console will turn o,
then the display will automacally cycle through the following
informaon:
• UI soware revision code (U major revision number, U
minor revision number, U test revision number)
• UI cycle GEE soware revision code (y major revision
number, y minor revision number, y test revision
number)
• UI HW GEE le soware revision code (H major revision
number, H minor revision number, H test revision
number)
• UI touch EEPROM revision code (o major revision
number, o minor revision number, o test revision
number)
• UI touch control soware revision code (t major
revision number, t minor revision number, t test
revision number)
• UI audio soware revision code (A major revision
number, A minor revision number, A test revision
number)
• ACU soware revision code (C major revision number,
C minor revision number, C test revision number)
• ACU GEE le revision code (h major revision number, h
minor revision number, h test revision number)
• MCU soware le revision code (n major revision
number, n minor revision number, n test revision
number)
• Cycle design revision code (d major revision number, d
minor revision number, d test revision number)
Exit Procedure
Pressing the POWER buon will exit Soware Version Display
and return washer to standby mode.
Fault/Error Codes
Refer to Fault/Error Codes chart on pages 5-9 to 5-11.
Fault/Error Code Display Method
Fault codes are displayed by alternately showing F# and E#. All
fault codes have an F# and an E#. The F# indicates the suspect
System/Category. The E# indicates the suspect Component
system.
Up to four Fault/Error codes may be stored. When the oldest
fault code is displayed, addional presses of the 3rd buon
will result in a triple beep, then display of the most recent fault
code. If each press of the 3rd buon results in a triple beep
and the display shows “888”, no saved fault codes are present.
Advancing Through Saved Fault/Error Codes
Procedure for advancing through saved fault codes:
Press and release
the 3rd buon used
to acvate Service
Diagnoscs
 beep tone 
most recent
fault code is
displayed
Repeat
 beep tone 
second most
recent fault code is
displayed
Repeat
 beep tone 
third most recent
fault code is
displayed
Repeat
 beep tone 
fourth most recent
fault code is
displayed
Repeat
 beep tone 
back to the most
recent fault code
Clearing Fault Codes
To clear stored fault codes, enter Service Diagnosc mode.
Then press and hold the 3rd buon used to enter Service
Diagnosc mode for 5 seconds. Once the stored fault codes
are successfully erased, the seven segment display will show
“888”.
EXITING SERVICE DIAGNOSTIC MODE
Use either of the two methods below to exit diagnosc mode.
• Pressing and holding the 1st buon used to acvate
the Service Diagnosc mode for 5 seconds.
• Pressing the POWER buon once or twice, depending
on diagnosc procedure.

Whirlpool Cabrio WTW8500DC Specifications

General

Style	Top-Loading
Color	Chrome Shadow
Washer Capacity	5.3 cu ft
Dryer Capactity	-
Max Spin Speed	850 RPM
Spin Speeds	2
Spin Class	D
Number of Cycles	26
Cycle Selections	Drain & Spin
Wash	Towels
Options	Clean Water
No spin and No heat	Extra Rinse
Hours	Delay Wash
Noise level	-
Temperature Selections	-
Cold)	Eco Warm
Internal Heater	yes
Delay Start / End	yes
Cycle Signal	yes
Steam	yes
Dispenser	single load
Energy Class	-
Annual Energy Consumption	196 kWh
Annual Water Consumption	-
Water Consumption Per Cycle	-
Voltage	120 V
Frequency	-
Current	15 A
Temperature Settings	5
Soil Levels	light, medium, normal, heavy
Smart Home	no

Weight and Dimensions

Depth	27-7/8 in
Height	42-1/8 in
Width	27-5/8 in
Net Weight	160 lb
