Whirlpool 2014 CABRIO
®
Direct Drive Washer
DIAGNOSTICS & TROUBLESHOOTING
For Service Technician Use Only
Display Washer
Funcon
Recommended
Procedure
Est. Time
in Seconds
001 Warm water lls through
the Detergent valve
If not water, use service test load control to
manually turn on and test the valve.
10
002 Cold water lls through
the Fabric Soener valve
If not water, use service test load control to
manually turn on and test the valve.
10
003 Hot water lls through
the Bleach/Oxi valve*
If not water, use service test load control to
manually turn on and test the valve.
10
004 Warm water lls through
the detergent valve to
minimum water level
If not water, use service test load control to
manually turn on and test the valve.
50-70
005 Validates pressure sensor If this step fails, replace the appliance
control unit.
Up to 5
006 Validates inlet thermistor If this step fails, go to and complete the
Temperature Thermistor test.
Up to 5
007 Validates IPM thermistor If this step fails, replace the appliance
control unit.
Up to 5
008 Turns on heater* If heater does not turn on, use service test
load control to manually turn on and test the
heater.
8
009 Recirculates* for 10
seconds
If water is not being recirculated, use service
test load control to test the recirculaon
pump.
10
010 Skip N/A ---
011 Lid will lock Lid must be closed. If lid does not lock, use
service test load control to manually test the
lid lock.
10
012 Skip N/A ---
013 Drain pump on for 15
seconds
If water is not draining, use service test load
control to test the drain pump.
20
Service Diagnoscs Execuon
When Service Diagnoscs is acvated, any load(s) that were manually commanded on will be turned o. Service Diagnoscs
will start and the step number within the Service Diagnoscs sequence will be shown on the display. NOTE: The basket must be
empty during this test.
Service Diagnosc Chart
* On models without bleach/oxi valve, heater, and/or recirculaon pump, steps 3, 8, and 9 will be skipped.

Whirlpool Cabrio WTW8500DC Specifications

General

Style	Top-Loading
Color	Chrome Shadow
Washer Capacity	5.3 cu ft
Dryer Capactity	-
Max Spin Speed	850 RPM
Spin Speeds	2
Spin Class	D
Number of Cycles	26
Cycle Selections	Drain & Spin
Wash	Towels
Options	Clean Water
No spin and No heat	Extra Rinse
Hours	Delay Wash
Noise level	-
Temperature Selections	-
Cold)	Eco Warm
Internal Heater	yes
Delay Start / End	yes
Cycle Signal	yes
Steam	yes
Dispenser	single load
Energy Class	-
Annual Energy Consumption	196 kWh
Annual Water Consumption	-
Water Consumption Per Cycle	-
Voltage	120 V
Frequency	-
Current	15 A
Temperature Settings	5
Soil Levels	light, medium, normal, heavy
Smart Home	no

Weight and Dimensions

Depth	27-7/8 in
Height	42-1/8 in
Width	27-5/8 in
Net Weight	160 lb
