Whirlpool Cabrio WTW8500DC User Manual

6-4
n
Whirlpool 2014 CABRIO
®
Direct Drive Washer
TESTING
For Service Technician Use Only
WIRING DIAGRAM
3$*(
FOR SERVICE TECHNICIAN’S USE ONLY
DO NOT REMOVE OR DESTROY
Wiring Diagram
IMPORTANT: Electrostatic discharge may cause damage to machine control electronics. See page 1 for
ESD information.
NOTE: Schematic shows lock switch open.
Figure 8 - Wiring Diagram
RECIRC.
PUMP
DRAIN
PUMP
NOT ON ALL MODELS
120 VAC PUMPS
& SHIFTER
SHIFTER
COIL
W
OR
W
LBU W
7 5 3 1
4 3 1 6
3 PHASE
BPM MOTOR
4 3 2 1
BK BR R
VS3 VS1 VS2
BPM MOTOR
DRIVE
NOT ON ALL MODELS
HEATER
ELEMENT
1 2
BK GY
1
2
3
BK
G
W
G
L1
G
N
120 VAC
POWER
CORD
AA BB
MOTOR
PLATE
CABINET
G/Y
RTN (VSS)
VALVE
THERMISTOR
SOFTENER
BLEACH/OXI
MAIN HOT
MAIN COLD
THERMISTOR
BK
BK
T
W
OR
V
R
BU
1
2
3
4
5
6
7
8
9
10
11
12
WATER INLET VALVE
120 VAC
GROUND CIRCUIT
5V
WIDE
RTN (VSS)
1 2 3
SMART UI
SPEAKER
BK BU Y
LOCK SW
LID SW
HOME SW
LOCK MOTOR
LOCK MOTOR
SW OUT
1
2
3
4
5
6
7
W
R
BK
BU
BR
G
GRAY
JACKET
DC LOCK
LOCK
LID
HOME
12 VDC MOTOR
1
3
1
3
1
3
1
3
1 3
BU
(NOT ON
ALL MODELS)
FULL WAVE
BRIDGE
RECTIFIER
NEUT
L1 N
L1
G
N
RECIRC.
NEU
DRAIN
PUMP
ON BOARD
PRESSURE
TRANSDUCER
PRESSURE
HOSE TO TUB
SHIFTER
HF RETURN
Main
Control
UI

Whirlpool Cabrio WTW8500DC Specifications

General

Style	Top-Loading
Color	Chrome Shadow
Washer Capacity	5.3 cu ft
Dryer Capactity	-
Max Spin Speed	850 RPM
Spin Speeds	2
Spin Class	D
Number of Cycles	26
Cycle Selections	Drain & Spin
Wash	Towels
Options	Clean Water
No spin and No heat	Extra Rinse
Hours	Delay Wash
Noise level	-
Temperature Selections	-
Cold)	Eco Warm
Internal Heater	yes
Delay Start / End	yes
Cycle Signal	yes
Steam	yes
Dispenser	single load
Energy Class	-
Annual Energy Consumption	196 kWh
Annual Water Consumption	-
Water Consumption Per Cycle	-
Voltage	120 V
Frequency	-
Current	15 A
Temperature Settings	5
Soil Levels	light, medium, normal, heavy
Smart Home	no

Weight and Dimensions

Depth	27-7/8 in
Height	42-1/8 in
Width	27-5/8 in
Net Weight	160 lb
