TESTING
Whirlpool 2014 CABRIO
®
Direct Drive Washer
n
6-1
Section 6:
Testing
This secon provides a wiring diagram, control board
specicaons, tesng procedures and strip circuits for the
“Whirlpool 2014 CABRIO® Top Load Direct Drive Washer.”
n Tesng: Safety Informaon
n Component Locaons
n Wiring Diagram
n Component Tesng
n TEST #1: Main Control
n TEST #2: Valves
n TEST #3a: Drive System - Shier
n TEST #3b: Drive System - Motor
n TEST #4: Keys and Encoders
n TEST #5: Temperature Thermistor
n TEST #6: Water Level
n TEST #7: Drain & Recirculaon Pump
n TEST #8: Lid Lock
n TEST #9: Heater Element
n Notes

Whirlpool Cabrio WTW8500DC Specifications

General

Style	Top-Loading
Color	Chrome Shadow
Washer Capacity	5.3 cu ft
Dryer Capactity	-
Max Spin Speed	850 RPM
Spin Speeds	2
Spin Class	D
Number of Cycles	26
Cycle Selections	Drain & Spin
Wash	Towels
Options	Clean Water
No spin and No heat	Extra Rinse
Hours	Delay Wash
Noise level	-
Temperature Selections	-
Cold)	Eco Warm
Internal Heater	yes
Delay Start / End	yes
Cycle Signal	yes
Steam	yes
Dispenser	single load
Energy Class	-
Annual Energy Consumption	196 kWh
Annual Water Consumption	-
Water Consumption Per Cycle	-
Voltage	120 V
Frequency	-
Current	15 A
Temperature Settings	5
Soil Levels	light, medium, normal, heavy
Smart Home	no

Weight and Dimensions

Depth	27-7/8 in
Height	42-1/8 in
Width	27-5/8 in
Net Weight	160 lb
