Navigation
5–6 976-0043-01-02
Set Point Buttons
The SET POINT buttons change the value of a parameter or select a mode
from the displayed menu.
• Press the SET POINT button (+) to move the cursor to the right or
raise an adjustable value.
• Press the SET POINT button (–) to move the cursor left or lower an
adjustable value.
Reset Factory Defaults
The Reset Defaults push-button at the bottom of the ICM refreshes the
LCD display.
Pressing this button when the “Press Resets for Factory Default” menu is
displayed resets the unit to the factory defaults. See “Press Reset for
Factory Defaults” on page 8–21 for instructions on using this feature.
Figure 5-6
ICM Set Point Push-buttons
Figure 5-7
ICM Reset Defaults button
CAUTION: Equipment Damage
Ensure all devices connected to the ALM or GSM are disabled prior to pressing
the Reset Factory Defaults button.
