Pre-Installation
976-0043-01-02 3–13
Figure 3-5
Wall Mounting using Plywood
Wall studs 16 inches
on center
Wallboard
Floor
Ceiling
Plywood
Set In ve r te r
OFF SRCH ON CH G
Sine Wave Plus
Inverter/Charger
Mounting
Holes (10)
Keyhole
Slots (4)
