Power Versus Efficiency
976-0043-01-02 A–11
Figure A-7 Sine Wave Plus Efficiency Curve for the SW Plus 4048
Figure A-8 Sine Wave Plus Efficiency Curve for the SW Plus 5548
SW Plus 4048 Efficiency Curve
0%
10%
20%
30%
40%
50%
60%
70%
80%
90%
10 0 %
0 500 1000 1500 2000 2500 3000 3500 4000
Output Power in Watts
Efficiency
M easurements made using resistive load bank and Yokogawa PZ4000 Power Analyzer
SW Plus 5548 Efficiency Curve
0%
10 %
20%
30%
40%
50%
60%
70%
80%
90%
100%
0 500 1000 1500 2000 2500 3000 3500 4000 4500 5000 5500
Output Power in Watts
Efficiency
Measurements made using resistive load bank and Yokogawa PZ4000 Power
Analyzer
