Advanced Setup
7–10 976-0043-01-02
Before You Begin Advanced Programming
The Sine Wave Plus is designed to provide advanced application
programming. Advanced applications include:
• SILENT SETUP - Sets the parameters for the Silent finish stage of
battery charging. This feature is programmed in Menu Heading 20.
See “20 Silent Setup Menu” on page 7–13 for information on
programming this feature.
• GRID USAGE - Sets parameters for when and how the utility grid is
used. It supports energy management applications such as
Time-of-Use Metering and Peak Load Shaving (SB Mode). It also
controls transfer of grid power to protect the batteries (BX Mode).
These features are programmed in Menu Heading 21 and 22.
See “21 Grid (AC1) Usage Menu” on page 7–16 and “22 Battery Xfer
(BX) Menu” on page 7–18 for information on programming this
features.
• AUXILIARY LOADS - Sets the parameters by which the relays in
the ALM are used. This feature is programmed in Menu Heading 23.
See “23 ALM Relays Menu” on page 7–19 for information on
programming these parameters.
• GENERATOR CONTROL AND SUPPORT - Sets the parameters for
starting a generator based on time, type of generator being used, and
the inverter’s voltage and current. This feature is programmed in
Menu Headings 24, 25 and 26.
See “24 Generator Timers Menu” on page 7–26 for information on
programming the generator to run based on “time” settings.
See “25 Gen Starting Details Menu” on page 7–29 for information on
programming the generator to run based on type of generator being
used.
See “26 Gen Auto Run Setup Menu” on page 7–38 for information on
programming the generator to run based on voltage or current
settings.
• SAVING/RESTORING SETTINGS - Saves or restores previously
programmed user settings. This feature can also restore factory
defaults.
