Before You Begin Programming
976-0043-01-02 6–9
Basic Setup Process
The Basic Setup procedure is comprised of the following items:
1. Setting the Time of Day – This sets the internal clock for all the
features requiring time functions.
See “10 Time of Day Setup Menu” on page 6–11 for instructions on
setting the Time of Day.
2. Selecting Inverter functions – This selects basic inverter operating
functions.
See “11 Inverter Setup Menu” on page 6–12 for instructions on
setting the Inverter functions.
3. Selecting Charger functions – This selects the basic charger functions.
See “12 Battery Charging Menu” on page 6–19 for instructions on
setting the Charger functions.
4. Selecting Grid Usage functions – This selects basic Grid Usage
functions.
See “13 AC Inputs Menu” on page 6–26 for instructions on setting
the Grid Usage functions.
5. Saving programmed parameters.
See “14 Save/Restore Settings Menu” on page 6–29 for instructions
on saving programmed parameters.
