Introduction
1–8 976-0043-01-02
Top
The top of the unit has the following features:
• Circuit Breaker - This circuit breaker protects the unit’s internal
wiring while the unit is inverter or charging. It is not used for the
pass-through current. This is not a branch-circuit rated breaker.
Separate output breakers are still required. If the button is protruding
from the chassis as shown in Figure 1-7, it means the circuit breaker
has tripped open. Press the breaker back in to reset it.
• Warnings Label
• Ratings Label
Figure 1-7 External Output Circuit Breaker
Top View of Sine Wave Plus Inverter/charger
Ratings Label
Circuit Breaker
AC End
DC End
Warnings Label
Circuit Breaker Open Circuit Breaker Reset
