Installation
3–2 976-0043-01-02
Pre-Installation
Before installing the Sine Wave Plus, read all instructions and cautionary
markings located in this manual.
Although the DC electrical system may be “low voltage”, significant
hazards may still be present, particularly from short-circuits of the battery
system. Inverter systems, by their nature, involve power from multiple
sources (inverter, generator, utility, batteries, solar arrays, etc.) that add
hazards and complexity that can be very challenging.
Tools Required
The following tools may be required for installing this equipment:
❐ Assorted Phillips screw drivers
❐ Level, pencil, and utility knife
❐ Slotted screw driver
❐ Wire strippers
❐ Assorted open-end wrenches
❐ Torque wrench
❐ Socket wrench and sockets
❐ Electrical tape
❐ Multi-meter (AC/DC volts)
Important:
Be sure to obtain the appropriate permits, if necessary, prior to
starting this installation.
Important:
Installations should meet all local codes and standards.
Installations of this equipment should only be performed by skilled personnel
such as qualified electricians and Certified Renewable Energy (RE) System
Installers. For a list of Xantrex Certified RE dealers, please visit our website at
www.XantrexREdealers.com.
WARNING: Personal Injury
The Sine Wave Plus is can weight up to 145 lbs. Always use proper lifting
techniques and have someone available to assist with lifting it during installation
to prevent personal injury.
