System Configuration
2–22 976-0043-01-02
See “Generator Starting Scenarios” on page 7–23 of this guide for
specific instructions on setting the generator-start/stop conditions.
Additional/Optional Equipment Considerations
The following components are available for use with the Sine Wave Plus.
Some of these items may be required depending upon the intended use of
the inverter to make the installation code-compliant. These components
are not provided with the inverter and must be purchased separately.
AC Conduit Box (ACCB)
The AC Conduit Box (ACCB) connects to the AC side of the inverter and
accepts AC conduit runs. The AC conduit box includes bypass/disconnect
breakers.
Important: Be sure to consult with your local inspector and/or utility
company to ensure complete compliance with local regulations.
Figure 2-3
AC Conduit Box
