Configuration Settings
B–14 976-0043-01-02
26D 24-hr Start Volts DC 10.0 to 35.5 24.6 20.0 to 71.0 49.2
26E 2-hr Start Volts DC 10.0 to 35.5 23.6 20.0 to 71.0 47.2
26F 15-min Start Volts DC 10.0 to 35.5 22.6 20.0 to 71.0 45.2
26G Read LBCO 30 sec Start LBCO setting
(11C)
22.0 LBCO setting
(11C)
44.0
27 Save/Restore Setup Menu See “27 Save/Restore Settings Menu” on page 7–39 for details.
27A Push INV now to save
Settings
Push INV now to save Settings
27B Push GEN to restore settings Push GEN to restore settings
27C Push GEN for Factory
Defaults
PUSH GEN for Factory Defaults
Table B-7
Advanced Setup Default and User Settings for the Sine Wave Plus 5548 Model
Advanced Setup Menus
Sine Wave Plus 5548
User Settings
Range/
Display
Default
Settings
20 Silent Setup Menu See “20 Silent Setup Menu” on page 7–13 for details.
20A Refloat High Volts DC 32.2 to 67.8 56.8
20B Refloat Low Volts DC 32.2 to 67.8 50.0
20C Float Done Amps AC 00 to 40 10
20D Must Float Time Min 00 to 255 05
21 Grid AC1 Usage Menu See “21 Grid (AC1) Usage Menu” on page 7–16 for details.
21A Grid Usage SB BX SB BX SB
21B Grid Usage Begin h:m 00:00 to 23:50 21:00
21C Grid Usage End h:m 00:00 to 23:50 21:00
22 Battery Xfer (BX) Menu See “22 Battery Xfer (BX) Menu” on page 7–18 for details.
22A High Xfer (HBX) Vdc 32.2 to 67.8 54.0
Table B-6
Advanced Setup Default and User Settings for the Sine Wave Plus 4024 and
4048 Models
Advanced Setup Menus
Sine Wave Plus 4024 Sine Wave Plus 4048
User
Settings
Range/
Display
Default
Settings
Range/
Display
Default
Settings
To Next Page
