Basic Setup Summary
976-0043-01-02 6–7
13 AC Inputs Menu See “13 AC Inputs Menu” on page 6–26 for details.
13A Grid (AC1) Amps AC 00 to 60 60 page 6–27
13B Gen (AC2) Amps AC 00 to 60 30 page 6–27
13C Input Upper Limit Vac 125 to 150 130 page 6–28
13D Input Lower Limit Vac 80 to 115 110 page 6–28
End Menu 13
14 Save/Restore Settings Menu See “14 Save/Restore Settings Menu” on page 6–29 for details.
14A Push INV now to save
settings
Push INV now to save
settings
page 6–29
14B Push GEN to restore settings Push GEN to restore
settings
page 6–29
14C Push GEN for factory
defaults
Push GEN for factory
defaults
page 6–30
End Menu 14
END BASIC SETUP MENU
Table 6-3 Basic Setup Menu Default Settings for the Sine Wave Plus 5548 Model
Basic Setup Menus
Sine Wave Plus 5548
See Page
Range/
Display Default
