Specifications and requirements
14
EMU38092
Specifications
“(AL)” stated in the specification data below
represents the numerical value for the alumi-
num propeller installed.
EMU2821V
Dimension and weight:
Overall length:
721 mm (28.4 in)
Overall width:
479 mm (18.9 in)
Overall height L:
1583 mm (62.3 in)
Overall height X:
F90A 1710 mm (67.3 in)
Motor transom height L:
536 mm (21.1 in)
Motor transom height X:
F90A 664 mm (26.1 in)
Dry weight (AL) L:
170 kg (375 lb)
Dry weight (AL) X:
F90A 173 kg (381 lb)
Performance:
Full throttle operating range:
5000–6000 r/min
Rated power:
F75A 55.2 kW (75 HP)
F90A 66.2 kW (90 HP)
Idle speed (in neutral):
650–750 r/min
Power unit:
Type:
4-stroke DOHC L4 16 valves
Total displacement:
1596 cm³ (97.4 c.i.)
Bore × stroke:
79.0 × 81.4 mm (3.11 × 3.20 in)
Ignition system:
TCI
Spark plug (NGK):
LFR5A-11
Spark plug gap:
1.0–1.1 mm (0.039–0.043 in)
Steering system:
Remote steering
Starting system:
Electric starter
Starting carburetion system:
Fuel injection
Valve clearance IN (cold engine):
0.17–0.24 mm (0.0067–0.0094 in)
Valve clearance EX (cold engine):
0.31–0.38 mm (0.0122–0.0150 in)
Battery rating (CCA/SAE):
380–1150 A
Battery rating (MCA/ABYC):
502–1370 A
Battery rating (RC/SAE):
124 minutes
Battery rating (CCA/EN):
430–1080 A
Battery rating (20HR/IEC):
70 Ah
Maximum generator output:
25 A
Lower unit:
Gear shift positions:
Forward-neutral-reverse
Gear ratio:
2.27 (25/11)
Trim and tilt system:
Power trim and tilt
Propeller mark:
K
Fuel and oil:
Recommended fuel:
Regular unleaded gasoline
Min. pump octane number (PON):
86
U6D63EE0.book Page 14 Friday, December 12, 2014 9:39 AM
©2019 Yamaha Motor Corporation, U.S.A.
