Yamaha F75 User Manual

Operation
57
EMU43892
Sending fuel (portable tank)
When using the portable fuel tank “A”, send
fuel to the outboard motor according to the
following procedure.
1. Loosen the air vent screw 2 or 3 turns.
2. Connect the fuel hose to the fuel joint on
the fuel tank.
3. Wipe up any spilled gasoline immediate-
ly with dry rags.
TIP:
Dispose rags properly according to local laws
or regulations.
4. When using the fuel tank on the boat, a
fuel valve may also be equipped on the
boat. Open the fuel valve.
TIP:
Check the boat’s manual for the position of
the fuel valve.
5. Squeeze the primer pump, with the ar-
row pointing up, until you feel it become
firm. During engine operation place the
tank horizontally, otherwise fuel cannot
be drawn from the fuel tank.
When using the portable fuel tank “B”, send
fuel to the outboard motor according to the
following procedure.
1. To loosen the air vent screw, turn it coun-
terclockwise until it stops.
ZMU02295
ZMU02024
1. Arrow
ZMU07580
U6D63EE0.book Page 57 Friday, December 12, 2014 9:39 AM
©2019 Yamaha Motor Corporation, U.S.A.

Yamaha F75 Specifications

General

Cylinders	4
Fuel Induction System	EFI (Electronic Fuel Injection)
Prop Shaft Horsepower	75 hp
Full Throttle RPM Range	5000-6000 RPM
Gear Ratio	2.15:1
Starting System	Electric
Engine Type	4-stroke
Alternator Output	25A
Steering Angle	35° from center, either direction
Shaft Length	20 in., 25 in.
Fuel Tank Capacity	N/A (External)
Recommended Fuel	Regular Unleaded (Minimum Pump Octane 87)
Warranty	3-Year Limited Warranty
