Yamaha XT660X Service Manual

4 - 19
CHAS
FRONT AND REAR BRAKES
EAS00577
FRONT AND REAR BRAKES
FRONT BRAKE PADS (XT660R)
T
R
.
.
40 Nm (4.0 m
•
kg, 29 ft
•
Ib)
T
R
.
.
14 Nm (1.4 m
•
kg, 10 ft
•
Ib)
1
1
5
4
5
2
6
3
Order Job/Part Q’ty Remarks
Removing the front brake pads
Remove the parts in the order listed.
1 Brake caliper bolt 2
Refer to “REPLACING THE FRONT
BRAKE PADS”.
2 Brake pad clip 1
3 Brake pad pin 1
4 Brake pad 2
5 Brake pad spring 2
6Bleed screw 1
For installation, reverse the removal pro-
cedure.
