Yamaha XT660X - Assembling the Starter Motor

8 - 27
– +
ELEC
STARTER MOTOR
EAS00772
ASSEMBLING THE STARTER MOTOR
1. Install:
• brush seat
1
NOTE:
_
Align the tab
a
on the brush seat with the slot
b
in the starter motor yoke.
2. Install:
• lock washer
NOTE:
Align the tabs
a
on the lock washer with the
groves in the front bracket.
a
3. Install:
• rear bracket
NOTE:
Align the slot
a
in the rear bracket with the tab
b
on the brush seat.
b
a
4. Install:
• starter motor yoke
1
• front bracket
2
• rear bracket
3
• O-rings
4
• bolts
NOTE:
_
Align the alignment marks
a
on the starter
motor yoke with the alignment marks
b
on the
front and rear brackets.
5. Install:
• starter motor gear
• circlip
1
2
3
4
4
a
b
b
New New
New
T
R
.
.
5 Nm (0.5 m · kg, 3.6 ft · lb)
