Yamaha XT660X Service Manual

4 - 80
CHAS
SWINGARM AND DRIVE CHAIN
EAS00700
SWINGARM AND DRIVE CHAIN
11
12
13
T
R
.
.
120 Nm (12.0 m
•
kg, 85 ft
•
lb)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
92Nm (9.2 m
•
kg, 66 ft
•
Ib)
T
R
.
.
7 Nm (0.7 m
•
kg, 5.1 ft
•
Ib)
T
R
.
.
23 Nm (2.3 m
•
kg, 17 ft
•
Ib)
T
R
.
.
23 Nm (2.3 m
•
kg, 17 ft
•
Ib)
T
R
.
.
23 Nm (2.3 m
•
kg, 17 ft
•
Ib)
T
R
.
.
59 Nm (5.9 m
•
kg, 43 ft
•
Ib)
T
R
.
.
48 Nm (4.8 m
•
kg, 35 ft
•
Ib)
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
LS
LS
LS
LS
LS
LS
LS
New
New
1
4
2
3
6
7
8
9
10
11
14
15
17
18
18
16
15
14
19
10
T
R
.
.
10 Nm (1.0 m
•
kg, 7.2 ft
•
Ib)
5
Order Job/Part Q’ty Remarks
Removing the swingarm and drive
chain
Remove the parts in the order listed.
Rear wheel Refer to “REAR WHEEL, BRAKE DISC,
AND REAR WHEEL SPROCKET”.
1 Right side heel plate 1
2 Brake master cylinder 1
3 Rear brake light switch 1
4 Right footrest/brake pedal assembly 1
5 Left side heel plate 1
6 Drive sprocket cover 1
Refer to “REMOVING THE DRIVE
SPROCKET” and “INSTALLING THE
SWINGARM”.
7 Drive chain guard 1
8 Nut/lock washer 1/1
9 Drive sprocket 1

Yamaha XT660X Specifications

General

Displacement	660cc
Bore x Stroke	100.0 mm x 84.0 mm
Compression Ratio	10.0:1
Fuel System	Fuel Injection
Ignition System	TCI
Transmission	5-speed
Final Drive	Chain
Rear Brake	Single disc, Ø 245 mm
Front Tyre	120/70 R17
Rear Tyre	160/60 R17
Maximum Power	48 HP (35.3 kW) @ 6, 000 rpm
Maximum Torque	58.4Nm (43.1lb-ft) @ 5, 250rpm
Front Suspension	Telescopic fork
Rear Suspension	Swingarm, (link suspension)
Fuel Tank Capacity	15 litres
Engine Type	Liquid-cooled, 4-stroke, single cylinder, SOHC, 4-valves
