Yamaha XT660X - Installing the Front Brake Caliper

4 - 47
CHAS
FRONT AND REAR BRAKES
EAS00634
INSTALLING THE FRONT BRAKE CALIPER
1. Install:
• brake pad springs
• brake pads
• brake pad pin(s)
• brake pad clip(s)
Refer to “FRONT BRAKE PADS”.
2. Install:
• brake caliper
1
• brake caliper bolts
2
• copper washers
• brake hose
3
• union bolt
4
WARNING
_
Proper brake hose routing is essential to
insure safe motorcycle operation. Refer to
“CABLE ROUTING” in chapter 2.
CAUTION:
_
XT660R
When installing the brake hose onto the
brake caliper
1
, make sure the brake pipe
a
touches the brake caliper body
b
.
XT660X
When installing the brake hose onto the
brake caliper
1
, make sure the brake pipe
a
touches the projection
c
on the brake
caliper.
È
XT660R
É
XT660X
4
3
1
2
È
1
4
2
3
É
a
c
É
a
b
È
T
R
.
.
40 Nm (4.0 m · kg, 29 ft · lb)
New
T
R
.
.
30 Nm (3.0 m · kg, 22 ft · lb)
