136
3 RECOMMENDED GREASES AND FLUIDS
1 = Engine oil
2 = Fuel tank
3 = Hydraulic oil
4 = Sprocket wheel
5 = Idle wheel
6 = Track roller
7 = Support roller
8 = Cooling system
9 = Tightener
• Select a fuel and an oil according to the machine's operating temperature.
• The machines may run on type B bio diesel.
• Always use a Yanmar long-life cooling fluid.
IMPORTANT
Do not mix different types of oils.If you need to top up the oil with an oil of a different
brand or type from the oil left in the tank, remove the remaining oil completely.
Components
Fluid
Temperatures °C
Quantity prescribed (L)
- -20 -10 0 10 20 30 +
Thermal engine Engine oil
SAE 10W CD
7,3
–
SAE 10W-30 CD
SAE 15W-40 CD
Travel gears
Box oil
SAE 90 (GL-4)
0,5
by reducer
Hydraulic circuit Hydraulic oil
ISO VG46
40 in the tank
22 the rest
Fuel tank Diesel
N° 2-D
41
–
N° 3-D
N° 3-D (S)
Cooling system
Long-life cooling fluid YANMAR POWER COOLANT B–36
3,8
Radiator
0,4
the expansion flask
