164
2
W
ORKING
DIMENSIONS
W
ARNING
The working dimensions are indicated for a machine equipped with the standard bucket
defined in the table of machine specifications.
The dimensions of the additional accessories and equipment installed on the machine
may modify the working dimensions, and must therefore
be taken into account before
using the machine.
Unit : mm
A
590
O
4510
B
540
Q
4980
C
640
R
51
10
D
85
S
3190
E
135
T
980
F
1550
U
2550
G
775
V
3070
H <swing>
2120 <1900>
Y
3330
I
375
Z
4720
K
2460
AA
320
L
325
AB
300
M
1480
AC
1250
N
2160
AD
1550
180
182
