5 Description of the driving position
31
5.3.7 Protection of pedals
• Fold the protection to lock the pedal. It may then be
used as a foot rest.
WARNING
To avoid the risk of any inappropriate or involuntary
use, always place the pedals in locked position when
they are not being used.
5.3.8 Boom rotation pedal
• Use this pedal to pivot the boom to the left or right.
A = Rotate right: press right
B = Rotate left: press left
N = If the pedal is released, it returns to the neutral po-
sition and the boom keeps its position.
5.4 Power socket
• The intake works when the ignition key is in the
ON position.Appliances up to 12V-120W (10A) may
be connected.
1 = Lid
2 = Power socket
IMPORTANT
Always close the lid if the plug is not used to seal for dust.
Prolonged use when the engine is switched off may damage the battery.
