Yanmar ViO38-6 - Upper Windscreen

5 Description of the driving position
39
5.10.2 Upper windscreen
Opening of the upper part of the windscreen
1. Grasp the handles and push the levers to the right and
left of the window until you hear a click for them to
unlock.
A = Handle
B = Lever
2. Remount the top part of the windscreen and drag it
backwards until it positions itself under the ceiling.
WARNING
Open the windshield carefully to avoid bump-
ing your head.
3. Lock it is using the safety lock located to the right and
left of the ceiling.
A = Safety lock
Closure of the upper part of the windscreen
1. Grasp the handles and push the levers to the right and
left of the window until you hear a click for them to
unlock.
A = Handle
2. Slowly lower the windscreen holding the handles.
3. Lock it using the safety lock to the right and left of the
window.
