Varispeed F7 Introduction
 Varispeed F7 Applications
The Varispeed F7 is ideal for the following applications.
• Fan, blower, and pump applications
• Conveyors, pushers, metal tooling machines, etc.
Settings must be adjusted to the application for optimum operation. Refer to Chapter 4 Trial Operation.
 Varispeed F7 Models
The Varispeed-F7 Series of Inverters included two Inverters in two voltage classes: 200 V and 400 V. Maximum motor
capacities vary from 0.4 to 300 kW (41 models).
Table 1.1 Varispeed F7 Models
Voltage
Class
Maximum
Motor
Capacity
kW
Varispeed F7
Specifications
(Always specify through the protective structure when ordering.)
Output
Capacity
kVA
Basic Model Number
Open Chassis
(IEC IP00)
CIMR-F7
Enclosed Wall-mounted
[IEC IP20, NEMA 1 (Type 1)]
CIMR-F7A
200 V Class
0.4 1.2 CIMR-F7A20P4
Remove the top and bottom cov-
ers from the Enclosed Wall-
mounted model.
20P41
0.75 1.6 CIMR-F7A20P7 20P71
1.5 2.7 CIMR-F7A21P5 21P51
2.2 3.7 CIMR-F7A22P2 22P21
3.7 5.7 CIMR-F7A23P7 23P71
5.5 8.8 CIMR-F7A25P5 25P51
7.5 12 CIMR-F7A27P5 27P51
11 17 CIMR-F7A2011 20111
15 22 CIMR-F7A2015 20151
18.5 27 CIMR-F7A2018
20220
20181
22 32 CIMR-F7A2022 20221
30 44 CIMR-F7A2030 20300 20301
37 55 CIMR-F7A2037 20370 20371
45 69 CIMR-F7A2045 20450 20451
55 82 CIMR-F7A2055 20550 20551
75 110 CIMR-F7A2075 20750 20751
90 130 CIMR-F7A2090 20900 20901
110 160 CIMR-F7A2110 21100 -
