Conformance to UL Standard
10-11
10
Conformance to UL Standard
To comply with UL standard, follow the appropriate installation instructions.
îš„Installation Site
Install the Inverter in a pollution degree 2 environment or equivalent.
îš„Specification of Closed-Loop Connector
The closed-loop connectors must be installed on conductors before installing to terminal blocks.
Use JST or equivalent closed-loop connectors shown below.
îš„Control Circuit Terminal
The Class 2 power supply must be used for the control circuits. See below table.
Table 10.2 JST Closed-Loop Connector Model
Inverter
Model CIMR-F7
JST Kit P/N
Input Output
2011 14-5 14-5
2015 38-6 22-6
2018 38-8 38-8
2022 60-8 38-8
2030 60-8 60-8
2037 100-10 100-10
2045 150-10 150-10
2055 60-10 (2perPh) 60-10 (2perPh)
2075 100-10 (2perPh) 80-10 (2perPh)
2090 150-12 (2perPh) 100-12 (2perPh)
2110 150-12 (2perPh) 150-12 (2perPh)
4022 22-6 14-6
4030 38-6 22-6
4037 38-8 38-8
4045 60-8 60-8
4055 70-8 70-8
4075 100-10 80-10
4090 60-10 (2perPh) 100-10
4110 70-10 (2perPh) 60-10 (2perPh)
4132 70-10 (2perPh) 70-10 (2perPh)
4160 80-12 (2perPh) 80-12 (2perPh)
4185 150-16 (2perPh) 150-16 (2perPh)
4220 325-16 (2perPh) 200-16 (2perPh)
4300 150-16 (4perPh) 150-16 (4perPh)
