Acceleration and Deceleration Characteristics
6-25
Acceleration and Deceleration Characteristics
This section explains the acceleration and deceleration characteristics of the Inverter.
 Setting Acceleration and Deceleration Times
Acceleration time indicates the time taken for the output frequency to climb from 0% to 100%. Deceleration
time indicates the time taken for the output frequency to reduce to 0%. The factory setting of the acceleration
time is C1-01, and the factory setting of the deceleration time is C1-02.
Related Parameters
Con-
stant
Number
Name Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
MEMO
BUS
Regis-
ter
V/f
V/f
with
PG
Open
Loop
Vec-
tor
Flux
Vec-
tor
C1-01
Accelera-
tion time 1
Sets the acceleration time to accelerate
from 0 to the maximum output frequency,
in 1-second units.
0.0 to
6000.0
*1
10.0 s
YesQQQQ200H
C1-02
Decelera-
tion time 1
Sets the deceleration time to decelerate
from the maximum output frequency to 0,
in 1-second units.
YesQQQQ201H
C1-03
Accelera-
tion time 2
The acceleration time when the multi-
function input “accel/decel time 1” is set
to ON.
YesAAAA202H
C1-04
Decelera-
tion time 2
The deceleration time when the multi-
function input “accel/decel time 1” is set
to ON.
YesAAAA203H
C1-05
Accelera-
tion time 3
The acceleration time when the multi-
function input “accel/decel time 2” is set
to ON.
No AAAA204H
C1-06
Decelera-
tion time 3
The deceleration time when the multi-
function input “accel/decel time 2” is set
to ON.
No AAAA205H
C1-07
Accelera-
tion time 4
The acceleration time when the multi-
function input “accel/decel time 1” and
“accel/decel time 2” are set to ON.
No AAAA206H
C1-08
Decelera-
tion time 4
The deceleration time when the multi-
function input “accel/decel time 1” and
“accel/decel time 2” are set to ON.
No AAAA207H
C1-10
Accel/
decel time
setting unit
0: 0.01-second units
1: 0.1-second units
0 or 1 1 No A A A A 209H
C1-11
Accel/
decel time
switching
frequency
Sets the frequency for automatic accelera-
tion/deceleration switching.
Below set frequency: Accel/decel time 4
Above set frequency: Accel/decel time 1
The multi-function input “accel/decel
time 1” or “accel/decel time 2” take prior-
ity.
0.0 to
400.0
*2
0.0 Hz No A A A A 20AH
0.0 to
300.0
*3
