YASKAWA Varispeed f7 User Manual

2-32
Installing and Wiring Option Boards
 Option Board Models and Specifications
Up to three option boards can be mounted in the Inverter. You can mount up one board into each of the three
places on the control board (A, C, and D) shown in Fig 2.24.
Table 2.14 lists the type of option boards and their specifications.
* Under development
Table 2.14 Option Board Specifications
Board Model Specifications
Mounting Loca-
tion
PG Speed Control Boards
PG-A2 Serial open-collector/complimentary inputs A
PG-B2 Phase A/B complimentary inputs A
PG-D2 Single line-driver inputs A
PG-X2 Phase A/B line-driver inputs A
Speed Reference Boards
AI-14U
Input signal levels
0 to 10 V DC (20 kΩ), 1 channel
4 to 20 mA (250 Ω), 1 channel
Input resolution: 14-bit
C
AI-14B
Input signal levels
0 to 10 V DC (20 kΩ)
4 to 20 mA (250 Ω), 3 channels
Input resolution: 13-bit with sign bit
C
DI-08 8-bit digital speed reference setting C
DI-16H2 16-bit digital speed reference setting C
DeviceNet Communication
Board
SI-N1 DeviceNet communications support C
Profibus-DP Communication
Board
SI-P1 Profibus-DP communications support C
InterBus-S Communication
Board *
SI-R InterBus-S communications support C
CANopen Communication
Board *
SI-S1 CANopen communications support C
CC-Link Communication
Board
SI-C CC-Link communications support C
L
ONWORKS Communica-
tion Board
SI-J
L
ONWORKS communications support C
SI-W1
MECHATROLINK Commu-
nication Board
SI-T MECHATROLINK communications support C
Analog Monitor Board
AO-08 8-bit analog outputs, 2 channels D
AO-12 12-bit analog outputs, 2 channels D
Digital Output Board
DO-08 Six photocoupler outputs and 2 relay outputs D
DO-02C 2 relay outputs D
