Console with a ø 80 ball module
Towing bar
The console with a ø 80 ball is only used to
connect semi-trailers with a hitching device designed
for a ø 80 ball.
Releasing the hitch, fig. (A):
By moving the lever (1) in the arrow direction you will
remove the locking wedge (2).
Locking the hitch, fig. (B):
By moving the lever (1) in the arrow direction you will
retract the locking wedge (2).
PCLPN054
Height of the towing bar can be adjusted within entire
extent of the adjustable height.
Only those farming mechanisms can be attached to the
towing bar that load it permanently downwards.
When working with the towing bar dismount the
multi-level hitch and pivoted pull bar.
PGPPN029
TRANSPORT USE
100
