Bleeding of hydraulic clutch circuit
PGPPN154
The liquid reservoir for control of the clutch is located on the left in front of the tractor cabin and is accessible
when the front engine bonnet is open
During bleeding observe the amount of liquid in the balancing tank to avoid intake of air.
1. Add the missing amount of the fluid in the equalizing vessel to the max. amount.
2. Remove the rubber cap, install the hose on the bleeder screw (1) on the tripping cylinder of the clutch
located on the left side of the tractor near the clutch housing and immerse the other end to th
e bottom of the
transparent vessel partly filled with the fluid for control of the clutch. The bleeder screw must be permanently
under pressure to prevent air penetration through its threads, therefore when doing this place the vessel at
least 300 mm above the bleeder screw.
3. Press fully the clutch pedal and keep it pressed in the lower position.
4. Release the bleeder screw by 1/4 revolution max.
5. Tighten the bleeder screw.
6. Release the clutch pedal.
7. Repeat the procedure until no air bubbles come out of the hose.
8. Remove the hose from the bleeder screw and install the rubber cap back on it.
Only new fluid can be added in the equalizing vessel. After two years of operation, replacement
of the fluid in the whole clutch release h
draulic circuit must be performed
