Activation of the rear PTO shaft - independent revolutions - common working mode
PHS18N015
The number of PTO shaft revolutions depends on the number of engine revolutions.
When the tractor is not going with its engine running and the clutch of the rear PTO shaft is deactivated:
A - Use the gear shift lever to select suitable speed of the rear PTO shaft.
B - Set proper display of revolutions on the display of the instrument panel according to selected revolutions
of the rear PTO shaft.
C - Move the gear shift lever of dependent and independent engine speed to the upper position to gear
independent revolutions of the rear PTO shaft.
D - Press the button on the right pillar of the cabin for at least one second to activate the rear PTO shaft.
The operator must sit on the driver's seat when pressing the button.
E - Rotation of the rear PTO shaft is indicated by displaying the number of revolutions on the display of the
instrument panel.
If the rear PTO shaft is active and the operator leaves the driver's seat for more than five
seconds, an audio signal is generated and the rear PTO shaft is deactivated. Reactivation is
erformed when the operator sits on the driver's seat b
pressin
the button on the right column of
the cabin.
Press the button on the right pillar of the cabin or on the panel of the outer hydraulic control
(according to the tractor equipment) to interrupt the torque transmitted by the rear PTO shaft.
PTO DRIVE OF AGRICULTURAL MACHINES
