Front PTO shaft
Activation of the front PTO shaft -
If the front PTO shaft is active, the tractor is not going and the operator leaves the driver's seat,
an audio signal is generated and after five seconds the rear PTO shaft is automatically deactivated.
Reactivation is performed when the operator sits on the driver's seat by pressing the button on the
right column of the cabin.>
If the front PTO shaft is active, the tractor is going and the operator leaves the driver's seat, an
audio signal is generated.
Front PTO shaft is equipped with a solid six or twent
-one
splined end point and it comes only in design of 1,000
revolutions.
Tractor may be equipped with front PTO shaft with varied
direction of spinning:
a - In compliance with the direction of engine
revolutions (standard)
b - Against the direction of engine revolutions
(*on request)
PCLPN057
The number of PTO shaft revolutions depends on the
number of engine revolutions.
When the tractor is not going with its engine running:
A - Press the button on the right column of the cabin or on
the panel of the outer hydraulic control (according to the
tractor equipment) for at least one second to activate the
front PTO shaft..
The operator must sit on the driver's seat when
ressin
the button
B - Rotation of the front PTO shaft is indicated by
displaying the number of revolutions on the display of the
instrument panel. The working mode is indicated by the
pictogram on the display of the instrument panel.
PHS18N024
PTO DRIVE OF AGRICULTURAL MACHINES
